Multi-spectral lighting (100 mm) KEYENCE CA-DRM10X industrial automation inspection

Keyence CA-DRM10X is a multi-spectral ring light source utilizing LED technology, supporting multiple wavelength emissions. Below are its core features:

Light Source Type

Equipped with a multi-spectral light source, supporting both LumiTrax illumination and standard monochromatic lighting (omnidirectional illumination).

Wavelengths (e. g. , UV, blue, green, orange, red, far-red, infrared) can be adjusted via the controller.

Operating temperature range: 0–40°C, humidity: ≤65% RH (non-condensing).

IP65-rated for dustproof and water-resistant installation environments.

The CA-DRM10X supports ring light mode and is suitable for machine vision applications such as dimensional measurement and defect detection. Its multi-spectral capability (covering 8 bands from UV to far-infrared) provides optimized illumination for different material surfaces, for example:

UV (405nm): High penetration, ideal for detecting coating defects on metal surfaces

Blue (457nm): High reflectivity, suitable for identifying surface flaws in transparent materials

Green (527nm): Color-sensitive, used to distinguish material or color variations

Infrared (860nm): Excellent penetration, capable of detecting hidden defects

Accessory Compatibility
The light source is compatible with dome accessories (CA-DRM10X DA series) and polarizing accessories (CA-DRM10X PA series), further expanding its application range. For example:

Polarizing accessories reduce stray light, improving inspection accuracy

Dome accessories are ideal for applications requiring uniform light distribution (e. g. , precision assembly inspection)

Price advantage

Brand - new and original

In stock

Short lead time.
